(A) CONTACTOR 230V50/60HZ

100-C sarjan kontaktori on suunniteltu ohjaamaan moottoreita ja muita kuormia. Kompakti koko, tilaa säästävä muotoilu ja alhainen virrankulutus.

3-napa, Nimellisvirta 9A, 230V AC 50/60Hz, Apukoskettimet 1 NO
IEC/EN 60947-1

Contactor, 9 A, 230V 50/60 Hz, AC, 3 Normally Open Poles, 230V AC 50/60 Hz, 1 NO Contacts & 0 NC Contacts, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load

Coil Voltage: 230 V AC
Number of poles: 3
Contact Current Rating: 9 A
Power Rating: 4 kW
Normal State Configuration: 3 NO
Contact Voltage Rating: 690 V AC
Number Of Auxiliary Contacts: 1
Width: 45 mm
Depth: 86.5 mm
Length: 81 mm
Maximum Operating Temperature: +60 °C
Minimum Operating Temperature: -25 °C
Terminal Type: Screw
