Managed Ethernet Switch 8 copper 10/100 ports + 2 combo 10/100 ports

Stratix 5700 Ethernet Switch 10 ports

1255,72  / sales pack Sales pack incl. 1 PCSReference price 1255,72 / 1PCS

By order

Product number: 1783BMS10CLProduct order number: 1783BMS10CLManufacturer's product number: 1783-BMS10CLProduct commodity code: 85176200

Stratix 5700 managed switches provide a secure switching infrastructure for harsh environments. You can connect the switches to network devices such as servers, routers, and other switches. In industrial environments, you can connect Ethernet-enabled industrial communication devices, including programmable logic controllers (PLCs), human machine interfaces (HMIs), drives, sensors, and I/O. Stratix switches contain an EtherNet/IP network interface.

The Stratix 5700 switch is DIN-rail mounted and has 8 x 10/100 Mbps copper ports and 2 x 10/100 Mbps (Copper Ports or SFP slots) combo ports.

Stratix 5700, 8 copper 10/100 ports, 2 combo(copper or SFP slot) 10/100ports, lite FW

Weight 1,683 kg
Quantity in the package: 1Unit: PCS

Total number of ports: 10
Number of ports 10/100 Mbps RJ45: 8
Number of combination ports 10/100 Mbps: 2
Number of combination-ports RJ45/Mini GBIC: 2
Layer 2: no
Layer 3: no
Manageable: yes
Ethernet: yes
Firmware type: lite

Power consumption, maximum: 17 W
Power dissipation: 17 W
Power input at 12 - 48V DC, class 2/SELV: 0,5 A

Mounting method: DIN rail (top hat rail)
Degree of protection (IP): IP30
Housing base material: open-style

Width: 91,4 mm
Height: 129,5 mm
Depth: 116,7 mm
Weight: 1,25 kg
Temperature, surrounding air, max: 60 °C
Temperature, non-operating: -40 °C
