I/O Expansion Module 8 Thermocouple/Analog Inputs

The IO-ATC8 is an I/O expansion module for Vision -series OPLC.

The module offers 8 inputs that may be set as either analog or thermocouple inputs via wiring, jumper and software settings.

The interface between the module and the OPLC is provided by an adapter.

The module may either be snap-mounted on a DIN rail, or screw-mounted onto a mounting plate.

8 Thermocouple/Analog inputs (T/C: J, K, T, B, E, N, R, S, 0.1° resolution. Analog: 12/14 bit, 0-10V, 0-20mA, 4-20mA)

Environmental: IP20/NEMA1
Operating temperature : 0…50°C
Storage temperature: -20…60°C
Relative Humidity (RH): 5% to 95% (non-condensing)
Dimensions (WxHxD): 80mm x 93mm x 60mm
Weight: 150 g
Mounting: Either onto a 35mm DIN-rail or screw- mounted
