General Purpose Relay 4CO 7A 230VAC

Industrial Relay 4CO 7A 230VAC

71,76  / sales pack Sales pack incl. 10 PCSReference price 7,18 / 1PCS

In stock (can be backordered)

Product number: 553482300040Product order number: 553482300040Manufacturer's product number: 55.34.8.230.0040Electrical number: 2517138Product commodity code: 85364900

Type 55.34 General purpose plug-in relay. 4 CO 7 A. Lockable test button + mechanical indicator. Sockets Series 94 for printed circuit board, solder or for 35mm rail mount (EN 60715) with push-in, screw or screwless terminals. Silver-nickel cadmium-free contact. Relay is ideal for general purpose applications.

Applications:

  • Automation for blinds, grilles and shutters
  • Control and management of electric power
  • Shipyards
  • Road / tunnel lighting
  • Hoists and cranes
  • Circuit breakers and switches
  • Control panels
  • Panels for electrical distribution

4-pole, 7A, 230V AC, 4CO, Lockable test button + mechanical indicator, Plug-in, Rohs.

Weight 0,033 kg
Quantity in the package: 10Unit: PCS

Series: 55.34
Type of relay: electromagnetic
Relay variant: industrial
Mounting: Socket, Plug-in
Leads: 2,8x0,5mm connectors
Contact configuration: 4PDT
Contact material: AgNi

Rated coil voltage: 230 VAC
Switching Current: 7 A
Coil Resistance: 17 kΩ
Number of Poles: 4
AC contacts rating @R (at resistive load): 7A / 250V AC
DC contacts rating @R (at resistive load): 7A / 30V DC
Coil power consumption: 1.5 VA
Coil current: 6 mA
Switched voltage: max. 220V DC, max. 400V AC

Dimensions (H x L x D): 27.7 x 20.7 x 35.8 mm
Operating temperature: -40...85 °C
