Emergency Stop Push Button

800FP-LMT44 Emergency Stop Push Button

30,06  / sales pack Sales pack incl. 1 PCSReference price 30,06 / 1PCS

In stock (can be backordered)

Product number: 800FPLMT44Product order number: 800FPLMT44Manufacturer's product number: 800FP-LMT44Product commodity code: 85389099

800F PB, 22mm Twist To Release E-Stop, 40 mm Twist to Release Lit, Red, Plastic, No Screw, None (Monolithic Circuit).

800F PB, 22mm Twist To Release E-Stop, 40 mm Twist to Release Lit, Red, Plastic, No Screw, None (Monolithic Circuit)

Weight 0,041 kg
Quantity in the package: 1Unit: PCS

Operator type: 40 mm twist to release lit
Operator function: 22 mm twist to release E-stop
Hole diameter: 22,5 mm
Diameter cap: 40 mm
Unlocking method: Turn-release
Spring-return: no
Operator construction/material: plastic
Colour button: red
With front ring: yes
Switching function latching: yes
Suitable for illumination: yes

Operator mechanical design life (cycles, min.): 300000
Contact block durability: 10000000 cycles
Contact block thermal current rating: 10 A

Operating temperature: -25 °C
Storage temperature: -40 °C
Humidity: ≤95% RH from 25...60 °C
Certifications: UL,UR, CSA, CCC, CE
Enclosure compatibility: IP69K, IP66, Type 4/4X/13 (Round plastic operator)
