Contactor 3P 9A 230V AC 50/60Hz

100-C Contactor offers space-saving and high-performance design. Contactors have low power consumption and offer high connection reliability and ease-of-wiring due to having two separate power connections per pole, saving you valuable time and money.

100-C contactors have reversible coil terminals, offer front and side mounting of auxiliary contacts, and can be attached to a 35mm DIN Rail mount or panel mounted.

3-pole, Nom. current 9A, 230V AC 50/60Hz, Auxiliaries 1 NO
IEC/EN 60947-1

Contactor, 9 A, 230V 50/60 Hz, AC, 3 Normally Open Poles, 230V AC 50/60 Hz, 1 NO Contacts & 0 NC Contacts, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load

Coil Voltage: 230 V AC
Number of poles: 3
Contact Current Rating: 9 A
Power Rating: 4 kW
Normal State Configuration: 3 NO
Contact Voltage Rating: 690 V AC
Number Of Auxiliary Contacts: 1
Width: 45 mm
Depth: 86.5 mm
Length: 81 mm
Maximum Operating Temperature: +60 °C
Minimum Operating Temperature: -25 °C
Terminal Type: Screw
