Lamp LED 025 5W 24-48VDC magnet, PIR

Compact LED lamp 025 is suitable for all types of panels and enclosures. The lamp have a very long service life thanks to the use of LED technology.

The power output allows up to 10 lamps to be connected to each other. Both the power input and output connectors snap lock into their sockets. With the integrated power unit and the plugs the lamp can quickly be connected.

• PIR motion sensor
• Wide voltage range
• Luminous flux 400 lm
• Color of light: 6,000 to 7,000 K (daylight white)
• Feed-through wiring

Operating voltage: 24 - 48 VDC
Frequency: 50/60 Hz
Switch: movement sensor
Mounting: Magnet fixing
Note: CCC approved

Power consumption: < 4 W
Luminous flux: 400 Lm at 120°
Light color: daylight, color temperature: 6,000 K to 7,000 K
Service life: 60.000 h at +20 °C
Connection: 2-pole connector with snap lock
AC: max. 2.5A / 240VAC, color: white
DC: max. 2.5A / 60VDC, color: blue

Mounting: magnet fixing
Torque: 2 Nm max.
Casing: plastic, transparent
Operating/Storage temperature: -40 to +60 °C / -40 to +85 °C
Operating/Storage humidity: < 90% RH (non-condensing)
Protection type/Protection class: IP20 / II (double insulated), 12VDC: IP20 / III (extra-low voltage)
